基本參數

Basic data

型      號Model

GNZ-3

GNZ-6

GNZ-9

GNZ-12

GNZ-18

GNZ-18

GNZ-24

GNZ-30

GNZ-38

GNZ-45

GNZ-53

GNZ-60

GNZ-75

濃縮池內直徑D（m）

Inner diameter of concentration pool（m）

3.6

6

9

12

18

20

24

30

38

45

53

60

75

濃縮池深度h（m）

Depth of concentration pool（m）

2.7

3.4

3.7

3.95

4.4

4.5

4.9

5.3

6.15

7.2

8．0

8.9

8.9

沉淀面積（m²）

Settling area（㎡）

10

28

63

113

254

314

452

700

1134

1590

2205

2826

4416

提耙高度（mm）

Lifting height (mm)

300

350

350

350

350

350

350

350

350

350

350

350

350

提耙速度mm/min

Lifting speed mm/min

5-30

5-30

5-30

5-30

5-30

5-30

5-30

5-30

5-30

5-30

5-30

5-30

5-30

耙架每轉時間(min)

Truss per revolution time (min)

1.4-3.2

2.3-5.4

3.5-8.1

4.7-11

7.0-16.2

7.8-18

9.4-22

11.5-27

15-36

20-48

26-67

26-67

26-67

傳動電機功率/kW

Drive motor power / kW

1.1

1.1

3

3

5.5

5.5

7.5

7.5

15

15

18.5

18.5

18.5

主軸最大扭矩(kNm)

Spindle maximum torque (kNm)

8.86

14.55

60.37

81.07

221.4

246.7

405.3

496

1294

1725

2765

2765

2765

驅動油泵排量ml/r

Drive oil pump displacement ml/r

2.5

2.5

10/13

10/13

13/16

13/16

16/25

16/25

40

40

40

40

40

液壓馬達排量ml/r

Hydraulic motor displacement ml/r

80

80

100×2

100×2

235×2

235×2

594×2

594×2

683×4

683×4

1000×4

1000×4

1000×4

外型尺寸/m

Outline dimension (m)

L

3.90

6.6

11.

15.

21.

23.

27

33.

41

48

57

64

79

H

4.80

5.50

5.80

6.90

8.0

8.4

9.0

9.50

10.95

12.

12

13

14.

說明：防腐型用于非中性介質，防腐型祼露面采用富鋅底漆+氯化氯丁橡膠漆或艦船專用漆的重防腐涂裝工藝，過流表面粘敷高性能耐磨損、耐酸堿橡膠層。祼露面和過流面均可根據您的要求，采用適合您工作介質的防護層。

Note: Anti-corrosion type is used for non-neutral medium and its exposed surface adopts heavy anti-corrosion coating process of zinc-rich primer & chlorinated chloroprene rubber paint or specific ship paint. The overflow surface is coated with high performance, wear resistant, acid & alkali resistant rubber layer. Both exposed and overflow surfaces can use a protective layer suitable for your working medium, depending on your requirements.
